John Deere X350 Parts and Parts Manual

John Deere x350 Parts

The John Deere X350 is a ride-on lawn tractor designed for medium to large lawns (up to 8,000 square meters). It’s known for its ease of use, featuring a comfortable seat, Twin Touch™ foot pedals for controlling movement, and a car-style dashboard.

A powerful 19.2 horsepower Kawasaki engine and hydrostatic transmission allow for efficient mowing. You can choose between a 42-inch mulching deck or a deeper deck with side discharge.

The X350 is a good option for those seeking a user-friendly and capable tractor at an affordable entry point in the riding lawn mower category.

John Deere x350 Specs

  1. Engine: The John Deere X350 typically features a 20-24 horsepower engine, depending on the specific model and year. These engines are typically made by Kawasaki or Briggs & Stratton.
  2. Transmission: Hydrostatic transmission with Twin Touch™ pedals for easy forward and reverse operation.
  3. Mower Deck: The mower deck size varies, but commonly it’s around 42 inches (107 cm) or 48 inches (122 cm). Some models may have options for different deck sizes.
  4. Cutting Height: Adjustable cutting heights typically range from 1 inch (2.5 cm) to 4 inches (10 cm) in quarter-inch increments.
  5. Turning Radius: The turning radius is approximately 16 inches (40.6 cm) for easy maneuverability in tight spaces.
  6. Fuel Capacity: The fuel tank usually has a capacity of around 3 gallons (11.4 liters), though this can vary slightly depending on the model.
  7. Seat: Comfortable seat with adjustable position to accommodate different operators.
  8. Tires: The X350 typically features turf-friendly tires suitable for both lawn mowing and light-duty yard work.
  9. Steering: The X350 usually features power steering for ease of control.
  10. Attachments: Various attachments and accessories are available for the X350, including baggers, mulching kits, snow blowers, and more. These allow the tractor to be used for a range of tasks beyond just mowing.

John Deere x350 Parts Diagram

There are several places where you can find a parts diagram for the John Deere X350 lawn and garden tractor:

  1. The GlobalMowerSpares website provides detailed parts diagrams for the X350 mower deck as well as the belt drive, pulleys, and idlers
  2. The Weingartz website has an illustrated parts lookup for the John Deere X350 lawn and garden tractor, including diagrams and part numbers.
  3. John Deere’s own parts catalog website hosts a PDF “Replacement Parts Guide” for the X350 that includes diagrams and part information for the engine, electrical, fuel and air, and other components.
  4. The John Deere website’s X350 owner information page links to various resources including operator’s manuals, maintenance information, and parts diagrams for the different mower deck sizes available.

John Deere x350 Deck Parts

Main Deck Parts

  1. Mower Deck Shell: This is the main housing of the mower deck where the cutting blades are housed.
  2. Cutting Blades: Typically, a mower deck will have two or three cutting blades that rotate to cut the grass.
  3. Spindles: Spindles are the components that connect the blades to the mower deck and allow them to rotate.
  4. Pulleys: Pulleys are used to transfer power from the mower’s engine to the cutting blades via the deck belt.
  5. Deck Belt: The deck belt drives the blades on the mower deck. Over time, belts may wear out and need replacement.
  6. Idler Pulleys and Tensioners: These components help maintain proper tension on the deck belt.
  7. Deck Wheels: Deck wheels help support the mower deck and control its height above the ground, preventing scalping of the lawn.
  8. Skid Plates: Skid plates are metal or plastic plates located on the underside of the deck to protect it from damage when mowing over rough terrain.
  9. Anti-Scalp Wheels: These wheels are typically attached to the mower deck and help prevent scalping on uneven terrain.
  10. Deck Wash Port: Some models feature a deck wash port for easy cleaning of the mower deck underside.
  11. Deck Hangers and Brackets: These are the components that connect the mower deck to the tractor frame.
  12. Springs and Hardware: Various springs, bolts, nuts, and other hardware are used to assemble and maintain the mower deck.

John Deere x350 Parts List

  1. Engine Parts:
    • Air filter
    • Oil filter
    • Spark plug
    • Fuel filter
    • Carburetor parts (if applicable)
    • Engine oil
  2. Transmission and Drivetrain Parts:
    • Hydrostatic transmission oil/filter
    • Drive belt
    • Transmission drive pulleys
    • Axle components
    • Differential parts
  3. Mower Deck Parts:
    • Mower blades
    • Spindles
    • Deck belt
    • Idler pulleys
    • Deck wheels
    • Skid plates
    • Deck hangers and brackets
    • Deck wash port components
  4. Electrical Parts:
    • Battery
    • Starter motor
    • Alternator
    • Ignition switch
    • Wiring harness
    • Solenoid
  5. Chassis and Frame Parts:
    • Frame components
    • Front axle parts
    • Steering components
    • Seat and seat components
    • Fenders
    • Bumper
  6. Tires and Wheels:
    • Turf tires
    • Tire tubes (if applicable)
    • Wheels and rims
    • Wheel bearings
  7. Attachments and Accessories:
    • Bagging system components
    • Mulching kit parts
    • Snow blower parts (if applicable)
    • Utility cart parts
    • Front blade parts
    • Front bumper attachment
  8. Miscellaneous Parts:
    • Filters (air, oil, fuel)
    • Lubricants and fluids
    • Fasteners (bolts, nuts, screws)
    • Springs
    • Hoses and clamps
  9. Operator’s Manual and Documentation:
    • Operator’s manual
    • Parts catalog
    • Service manual

John Deere x350 Parts Manual

Main Sections :

  1. Introduction: This section may provide an overview of the manual, including its purpose, how to use it, and any important safety information.
  2. Table of Contents: A detailed table of contents listing all the sections and subsections of the manual for quick navigation.
  3. Illustrated Parts Diagrams: These diagrams visually depict the different assemblies and subassemblies of the John Deere X350 lawn tractor. Each part is typically labeled with a reference number for easy identification.
  4. Part Number Index: An alphabetical index listing all the parts included in the manual along with their corresponding reference numbers. This index helps users quickly locate specific parts by their part numbers.
  5. Parts List: A comprehensive list of all the parts and components of the John Deere X350, organized by category or system. Each part is typically listed with its reference number, description, and quantity.
  6. Assembly Instructions: Some manuals may include assembly instructions for specific components or attachments of the lawn tractor. These instructions may include diagrams, step-by-step procedures, and recommended tools.
  7. Maintenance and Service Parts: Information on maintenance items such as filters, lubricants, belts, and other consumable parts. This section may also include service intervals and recommended replacement schedules.
  8. Troubleshooting Guide: Some manuals may include a troubleshooting guide to help users diagnose common issues with their John Deere X350 lawn tractor. This section may provide symptom descriptions, possible causes, and recommended solutions.
  9. Warranty Information: Information about the warranty coverage for the John Deere X350 and instructions on how to obtain warranty service or replacement parts.
  10. Appendices: Additional information or resources related to parts and maintenance of the lawn tractor, such as torque specifications, wiring diagrams, or parts cross-reference tables.

John Deere x350 Problems

Common Problems Include :

  1. Starting Issues: Some users have experienced difficulties starting the engine, which could be due to a variety of factors such as a weak battery, dirty spark plug, or fuel system issues.
  2. Transmission Problems: Issues with the hydrostatic transmission, such as loss of power, difficulty changing gears, or transmission fluid leaks, have been reported by some users.
  3. Mower Deck Issues: Problems with the mower deck, including uneven cutting, belt slipping, or excessive vibration, can affect the quality of mowing and may require adjustment or replacement of parts.
  4. Electrical Problems: Electrical issues such as blown fuses, malfunctioning lights, or problems with the ignition system have been reported by some users.
  5. Steering and Handling Issues: Users have reported problems with the steering system, including stiffness, play in the steering wheel, or difficulty turning, which may be caused by worn components or improper adjustment.
  6. Engine Performance: Issues related to engine performance, such as rough idling, loss of power, or excessive smoking, could be caused by various factors such as dirty air filters, fuel system problems, or engine wear.
  7. Tire Problems: Tire punctures, leaks, or uneven tire wear can affect traction and overall performance.
  8. Deck Belt Problems: The deck belt may wear out over time, causing it to slip or break, which can affect the operation of the mower deck.
  9. Fuel System Issues: Problems with the fuel system, such as clogged fuel filters, dirty carburetor, or fuel contamination, can lead to engine performance issues.
  10. General Wear and Tear: Like any mechanical device, the John Deere X350 may experience general wear and tear over time, requiring routine maintenance and occasional repairs.

John Deere x350 Attachments

Common attachments include :

  1. Mower Deck Attachments:
    • Mulching Kit: Converts the mower deck to mulch grass clippings, promoting a healthier lawn.
    • Bagger System: Collects grass clippings, leaves, and other debris for easy disposal.
    • Lawn Striping Kit: Creates professional-looking stripes on the lawn for added aesthetics.
  2. Snow Removal Attachments:
    • Snow Blower: Attaches to the front of the tractor to quickly and efficiently clear snow from driveways and walkways.
    • Snow Blade: Allows you to push snow aside, directing it where you want it to go.
  3. Utility and Hauling Attachments:
    • Rear-mounted Utility Cart: Used for hauling yard waste, tools, and other materials around the property.
    • Front-mounted Blade: Allows you to push dirt, gravel, or other materials, as well as snow.
  4. Lawn Care Attachments:
    • Front Bumper: Adds protection to the front of the tractor and provides a mounting point for additional accessories.
    • Lawn Aerator: Helps improve soil compaction and promotes healthy grass growth by allowing air, water, and nutrients to penetrate the soil.
  5. Miscellaneous Attachments:
    • Sun Canopy: Provides shade and protection from the sun for the operator during hot days.
    • Seat Cover: Protects the tractor seat from weather damage and wear.
  6. Towing Attachments:
    • Tow-Behind Sprayer: Allows you to apply herbicides, pesticides, and fertilizers to large areas.
    • Lawn Roller: Compacts soil and levels uneven ground, resulting in a smoother lawn surface.
  7. Lighting Attachments:
    • Work Lights: Provides additional illumination for working in low-light conditions or during evening hours.

John Deere x350 Reviews

Common points made in reviews include :

  1. Durability: Many users appreciate the durability and build quality of the John Deere X350. It’s often praised for its sturdy construction, reliable performance, and long-lasting components.
  2. Mowing Performance: The X350 is known for its excellent mowing performance. Users often commend its ability to deliver a clean, even cut, even on uneven terrain. The mower deck’s design and quality of cut are frequently praised.
  3. Comfort and Ergonomics: The operator’s comfort is another area where the X350 receives positive feedback. Its comfortable seat, ergonomic controls, and smooth operation contribute to an enjoyable mowing experience, even during long sessions.
  4. Ease of Use: Many users find the X350 easy to operate, thanks to features like the hydrostatic transmission, easy steering, and intuitive controls. The Twin Touch™ pedals for forward and reverse movement are often appreciated for their simplicity and convenience.
  5. Versatility: The X350’s compatibility with various attachments and accessories adds to its appeal. Users appreciate the versatility it offers, allowing them to tackle a wide range of tasks beyond just mowing, such as snow removal, hauling, and lawn care.
  6. Reliability: John Deere’s reputation for reliability is often reflected in reviews of the X350. Users frequently mention its consistent performance and minimal downtime, with few reported issues or breakdowns.
  7. Service and Support: John Deere’s extensive dealer network and customer support services are often cited as positives by users. Access to parts, servicing, and knowledgeable staff contributes to a positive ownership experience.
  8. Price: While the initial purchase price of the X350 may be higher compared to some competing models, users often see it as a worthwhile investment due to its quality, performance, and long-term value.

John Deere x350 Oil Filter and Oil Capacity

Oil Filter:

  • The John Deere X350 uses the AM125424 oil filter.
  • This oil filter is compatible with other John Deere models like the X300, X500, LT150, LR175, and L100 series.5

Oil Capacity:

  • The engine oil capacity for the John Deere X350 is 1.8 quarts (1.7 liters).
  • The recommended oil type is Turf-Gard 10W30.
  • The oil should be changed every 100 hours of operation.

In summary, the John Deere X350 requires the AM125424 oil filter and has an engine oil capacity of 1.8 quarts (1.7 liters) of Turf-Gard 10W30 oil, which should be changed every 100 hours.

John Deere x350 – oil change

  1. Run the engine for about 5 minutes to warm up the oil before changing it.
  2. The oil capacity for the X350 is 1.8 quarts (1.7 liters) of Turf-Gard 10W30 oil.
  3. The oil filter used is the AM125424 filter, which is compatible with other John Deere models like the X300, X500, LT150, LR175, and L100 series.
  4. To change the oil, first locate the drain plug, usually on the bottom of the engine, and place a container underneath to catch the old oil.
  5. Unscrew the drain plug and allow the oil to fully drain out.
  6. Once drained, replace the drain plug and tighten it back up.
  7. Locate the oil filter, typically accessible from the top or side of the engine, and use an oil filter wrench to remove it.
  8. Apply a thin coat of new oil to the gasket of the new filter, then screw on the new filter by hand until secure.
  9. Unscrew the oil fill cap and slowly pour in the new 1.8 quarts (1.7 liters) of Turf-Gard 10W30 oil.
  10. Check the dipstick to ensure the oil level is between the 4 and 8 hash marks, which is the proper level
  11. Replace the oil fill cap and run the engine for a few minutes, then recheck the oil level and top up if needed.

John Deere x350 Battery

  • The John Deere X350 uses a 12V, 340 CCA (cold cranking amps) battery.
  • The specific battery model recommended for the X350 is the MCYP340PF.
  • This battery is compatible with a wide range of other John Deere models, including lawn tractors, utility vehicles, and zero-turn mowers.
  • The battery is a wet-charged type, meaning it needs to be filled with battery acid before use.
  • John Deere offers this replacement battery as a genuine OEM part that can be purchased from authorized dealers and retailers.
  • The 340 CCA rating indicates it is a standard size for lawn and garden equipment.

John Deere x350 Bagger

  1. The X350 is compatible with a 7-bushel (247-liter) two-piece rear bagger accessory.
  2. The specific bagger model is the 42A 2-bag, 250 L (7 bu) powered material collection system.
  3. The bagger can be ordered separately from the tractor and is an optional accessory.
  4. The Green Part Store website provides a parts lookup and ordering for the 2-bag rear bagger system specifically for the X350 model.

John Deere x330 v x350

A comparative overview of the differences between the two models:

Engine:

  • X330: Typically equipped with a 20-22 horsepower engine, depending on the specific model and year.
  • X350: Generally features a 20-24 horsepower engine, providing slightly more power than the X330.

Transmission:

  • Both the X330 and X350 typically come with hydrostatic transmissions, offering smooth operation and easy control.

Mower Deck:

  • The X330 and X350 offer various mower deck sizes, typically around 42 inches (107 cm) or 48 inches (122 cm). However, specific options may vary depending on the model year and region.

Cutting Height:

  • Adjustable cutting heights are available on both models, typically ranging from 1 inch (2.5 cm) to 4 inches (10 cm) in quarter-inch increments.

Turning Radius:

  • Both models feature a similar turning radius of approximately 16 inches (40.6 cm), providing good maneuverability in tight spaces.

Fuel Capacity:

  • The fuel tank capacity is usually similar for both models, offering around 3 gallons (11.4 liters) of fuel capacity.

Seat and Comfort:

  • Both the X330 and X350 are designed with operator comfort in mind, featuring adjustable seats and ergonomic controls.

Attachments and Accessories:

  • Both models support a wide range of attachments and accessories for added versatility, including baggers, mulching kits, snow blowers, and more.

Price:

  • The X330 typically comes at a lower price point compared to the X350, making it a more budget-friendly option for those seeking a reliable lawn tractor with fewer premium features.

Overall Performance:

  • While both the X330 and X350 offer reliable performance and durability, the X350 may provide slightly more power and features, making it suitable for larger properties or heavier-duty tasks.

John Deere x350 Weight

  1. With the 48-inch (122 cm) mower deck:
    • The weight is 261 kg (575 lb).
  2. With the 42-inch (107 cm) mower deck:
    • The weight is 252 kg (556 lb).

The 48-inch mower deck has a 23% heavier overall weight compared to the previous 48-inch Edge Xtra deck. Similarly, the 42-inch mower deck has a 16% heavier overall weight than the previous 42-inch Edge Xtra deck.

John Deere x350 Owners Manual

Common sections :

  1. Introduction: This section may provide an overview of the manual, including its purpose, how to use it, and any important safety information.
  2. Safety Information: Essential safety guidelines and precautions for operating the lawn tractor safely, including information on hazards, protective gear, and safe operating practices.
  3. Product Identification: Details on how to identify the specific model and serial number of your John Deere X350, as well as information on where to find this information on the tractor.
  4. Assembly Instructions: Step-by-step instructions for assembling the lawn tractor if it was purchased unassembled or if any components need to be installed.
  5. Controls and Instruments: Information on the various controls, switches, and instruments on the tractor’s dashboard, including their functions and how to operate them.
  6. Operating Instructions: Detailed instructions on how to operate the lawn tractor safely and effectively, including starting and stopping the engine, engaging the mower deck, adjusting cutting height, and more.
  7. Maintenance and Service: Guidelines for routine maintenance tasks such as checking and changing oil, inspecting and replacing air filters, lubricating moving parts, and other recommended maintenance procedures.
  8. Troubleshooting: A troubleshooting guide to help users diagnose and resolve common issues with their John Deere X350 lawn tractor, including symptoms, possible causes, and recommended solutions.
  9. Storage: Information on how to store the lawn tractor properly during periods of non-use, including recommendations for fuel, battery, and maintenance.
  10. Specifications: Technical specifications and performance data for the John Deere X350, including engine specifications, dimensions, capacities, and other relevant information.
  11. Warranty Information: Details on the warranty coverage for the John Deere X350, including warranty duration, coverage limitations, and how to obtain warranty service.
  12. Index: A comprehensive index of topics covered in the manual, allowing users to quickly locate specific information.

John Deere x350 48 Inch Deck

Key details about the John Deere X350 with the 48-inch mower deck:

  1. The weight of the X350 with the 48-inch mower deck is 607 lb (275 kg).
  2. The width of the X350 with the 48-inch mower deck is 62.6 in (1590 mm).
  3. The X350 with the 48-inch Accel Deep mower deck is compatible with optional accessories like the MulchControl kit
  4. The 48-inch mower deck has a 23% heavier overall weight compared to the previous 48-inch Edge Xtra deck.
  5. The 48-inch mower deck provides a 48-inch (122 cm) cutting width.

The cutting width of the John Deere X350 with the 48-inch mower deck is 48 inches (122 cm).

John Deere x350 Snow Blower

  1. Model Compatibility: The snow blower attachment compatible with the John Deere X350 is typically a front-mounted, two-stage snow blower designed specifically for this model.
  2. Clearing Width: The clearing width of the snow blower attachment may vary, but it’s commonly around 44 to 47 inches (112 to 119 cm), allowing you to clear a wide path with each pass.
  3. Two-Stage Design: The snow blower attachment typically features a two-stage design, with an auger to gather and break up the snow, followed by an impeller to discharge the snow through the chute.
  4. Hydraulic Chute Rotation: Many snow blower attachments for the X350 come with hydraulic chute rotation, allowing you to easily adjust the direction of the snow discharge from the operator’s position.
  5. Auger Height Adjustment: Some models may feature adjustable auger heights, allowing you to set the height based on the depth of the snow and the surface you’re clearing.
  6. Compatibility Kit: Depending on the model year and configuration of your John Deere X350, you may need to purchase a compatibility kit or additional hardware to install the snow blower attachment.
  7. Installation: Installation of the snow blower attachment typically requires removing the mower deck and attaching the snow blower to the front of the tractor using the provided mounting hardware. Instructions for installation are usually included with the attachment.
  8. Operation: Once installed, operating the snow blower attachment is similar to operating a standalone snow blower. You can engage the auger and impeller using the tractor’s power take-off (PTO) system and adjust the chute direction and deflector as needed.
  9. Maintenance: Regular maintenance of the snow blower attachment, such as lubricating moving parts, checking for loose bolts, and inspecting the auger and impeller, is essential to ensure optimal performance and longevity.

John Deere x350 Mulch Kit

The X350 is compatible with a mulching system as an optional accessory.

  1. The X350 can be equipped with a 42A Mulching System, which includes a standard mulch kit.
  2. John Deere offers a Genuine John Deere Mulch Control Kit for the 42-inch deck on the X350 model.
  3. The Mulch Control Kit includes the necessary brackets, screws, and a grass deflector to retrofit the X350 with an electric one-touch mulching system.
  4. The mulch blades required for the 42-inch mulch deck on the X350 are the AM140332 model, which are a left and right pair of mulch blades.

John Deere x350 Dimensions

Overall Length:

  • 71.5 in (1817 mm)

Wheelbase:

  • 49.4 in (1255 mm)

Width with Mower:

  • 50.5 in (1283 mm)
  • 51.2 in (1300 mm) with mower deflector raised for storage3
  • 38 in (964 mm) without mower

Height:

  • 46.1 in (1171 mm)

Weight:

  • 543 lb (246 kg) for the mower, without fuel

So in summary, the key dimensions of the John Deere X350 are:

  • Overall Length: 71.5 in (1817 mm)
  • Wheelbase: 49.4 in (1255 mm)
  • Width with Mower: 50.5 in (1283 mm), 51.2 in (1300 mm) with deflector raised
  • Height: 46.1 in (1171 mm)
  • Weight: 543 lb (246 kg) for the mower, without fuel

John Deere x350 Engine

  1. Engine Type: The X350 is equipped with a Kawasaki FR651V V-twin air-cooled gasoline engine.
  2. Engine Displacement: The engine displacement is 44.3 cu. in. (726 cc).
  3. Engine Power: The engine produces 21.5 hp (16.0 kW) of power.
  4. Fuel Tank Capacity: The fuel tank has a capacity of 3.3 gallons (12.5 liters).
  5. Charging System: The X350 has a 15-amp flywheel alternator charging system.
  6. Battery: The tractor uses a 12V, 340 CCA battery.

In summary, the John Deere X350 is powered by a 21.5 hp (16.0 kW), 726 cc Kawasaki V-twin air-cooled gasoline engine, with a 3.3 gallon fuel tank and a 15-amp charging system. This engine provides the power and reliability needed for the X350 lawn tractor.

John Deere s240 v x350

Engine:

  • S240: Typically equipped with a 17.5-22 horsepower engine, depending on the specific model and year. The engine is usually smaller compared to the X350.
  • X350: Generally features a 20-24 horsepower engine, providing more power than the S240.

Transmission:

  • Both the S240 and X350 typically come with hydrostatic transmissions, offering smooth operation and easy control.

Mower Deck:

  • The S240 and X350 offer various mower deck sizes, typically around 42 inches (107 cm) or 48 inches (122 cm). However, specific options may vary depending on the model year and region.

Cutting Height:

  • Adjustable cutting heights are available on both models, typically ranging from 1 inch (2.5 cm) to 4 inches (10 cm) in quarter-inch increments.

Turning Radius:

  • Both models feature a similar turning radius of approximately 16 inches (40.6 cm), providing good maneuverability in tight spaces.

Fuel Capacity:

  • The fuel tank capacity is usually similar for both models, offering around 2.1 gallons (7.9 liters) of fuel capacity.

Seat and Comfort:

  • Both the S240 and X350 are designed with operator comfort in mind, featuring adjustable seats and ergonomic controls.

Attachments and Accessories:

  • Both models support a wide range of attachments and accessories for added versatility, including baggers, mulching kits, snow blowers, and more.

Price:

  • The S240 typically comes at a lower price point compared to the X350, making it a more budget-friendly option for those seeking a reliable lawn tractor with fewer premium features.

Overall Performance:

  • While both the S240 and X350 offer reliable performance and durability, the X350 may provide slightly more power and features, making it suitable for larger properties or heavier-duty tasks.

John Deere x350 – Replace Mower Belt

  1. Preparation:
    • Park the tractor on a flat, level surface and set the parking brake.
    • Turn off the engine and remove the ignition key.
    • Allow the engine and mower deck to cool down if they’ve been in use.
  2. Remove the Mower Deck:
    • Lower the mower deck to its lowest cutting height.
    • Locate the belt tensioner and release the tension on the mower belt by moving it with your hand or using a wrench.
    • Remove the belt from the pulleys and idler arms.
    • Carefully slide the mower deck out from under the tractor.
  3. Remove the Old Belt:
    • Note the routing of the old belt before removing it. Take a picture or make a sketch if necessary for reference during installation.
    • Slide the old belt off the pulleys and idler arms, taking note of how it is routed.
  4. Install the New Belt:
    • Route the new belt onto the pulleys and idler arms according to the routing diagram you noted earlier.
    • Ensure the belt is properly seated in all the pulleys and idlers, and there are no twists or kinks in the belt.
  5. Reattach the Mower Deck:
    • Slide the mower deck back under the tractor.
    • Reconnect the mower belt to the pulleys and idler arms, ensuring it is properly tensioned.
    • If necessary, refer to your owner’s manual for specific instructions on adjusting the belt tension.
  6. Test the Belt:
    • Once the belt is installed, start the engine and engage the mower deck to test the belt’s operation.
    • Ensure the belt is tracking properly on all the pulleys and idlers, and there are no unusual noises or vibrations.
  7. Final Checks:
    • Double-check the routing of the belt to ensure it matches the diagram and is properly seated on all pulleys and idlers.
    • Adjust the belt tension if necessary to ensure proper operation.
    • Once satisfied with the installation, lower the mower deck to your desired cutting height.
  8. Maintenance:
    • Periodically check the mower belt for wear and replace it as needed to maintain optimal performance.

John Deere 1025r Parts and Parts Manual

John Deere 1025r Parts

The John Deere 1025R is a compact utility tractor that has become a popular choice for homeowners, landscapers, and small-scale farmers. This versatile machine is known for its maneuverability, power, and wide range of attachments that allow it to tackle a variety of tasks.

With its 25-horsepower engine and hydrostatic transmission, the 1025R provides smooth and efficient operation, making it a reliable workhorse for a variety of applications.

John Deere 1025r Specs

  1. Engine:
    • 3-cylinder diesel engine
    • Displacement: 1.1 liters (68 cubic inches)
    • Gross horsepower: Approximately 24 horsepower
    • Engine manufacturer: Yanmar
  2. Transmission:
    • Hydrostatic transmission with Twin Touch™ pedals
    • Two-range transmission with infinite speeds within each range
    • Four-wheel drive (4WD) standard
  3. PTO (Power Take-Off):
    • Rear PTO with standard 540 RPM
    • Mid PTO available as an option
  4. Hydraulics:
    • Hydraulic system capacity: Approximately 6.3 gallons (24 liters)
    • Hydraulic pump output: Approximately 3.3 gallons per minute (12.5 liters per minute)
    • Category 1 3-point hitch with telescoping draft links
  5. Dimensions:
    • Overall length (with 120R loader): Approximately 107 inches
    • Wheelbase: Approximately 57 inches
    • Ground clearance: Approximately 8 inches
  6. Weight:
    • Operating weight (with 120R loader and ballast box): Approximately 1,555 pounds
  7. Tires:
    • Standard tire size (front): 18×8.50-10
    • Standard tire size (rear): 26×12.00-12
  8. Other Features:
    • Operator station designed for comfort and convenience
    • Optional attachments include loaders, backhoes, mowers, and more
    • Easy-to-use controls and ergonomic layout for efficient operation

John Deere 1025r Parts Diagram

The John Deere 1025R parts diagram can be found on the Weingartz website, which provides an illustrated diagram of the various components and parts for this compact utility tractor model.

Additionally, the John Deere website offers access to owner information, including parts diagrams and service manuals, for the 1025R. These resources provide detailed schematics and part numbers to help identify and order replacement parts for the 1025R.

John Deere 1025r Mower Deck Parts

Common parts include

  1. Mower Blades: These are the cutting blades attached to the mower spindle. They come in pairs and are responsible for cutting the grass.
  2. Mower Spindles: Spindles are shafts that hold the mower blades in place and allow them to rotate. They are connected to the mower deck housing.
  3. Mower Deck Housing: This is the main structure of the mower deck that encloses the blades and spindles. It provides support and protection for the cutting components.
  4. Deck Belt: The deck belt is a reinforced rubber belt that drives the mower blades. It connects the mower deck to the tractor’s power take-off (PTO) system.
  5. Idler Pulleys: Idler pulleys help maintain tension on the deck belt and guide its path. They ensure proper engagement and operation of the belt.
  6. Tension Springs: These springs are used to adjust and maintain the tension of the deck belt. They are connected to the idler pulleys and deck engagement system.
  7. Deck Wheels: Deck wheels are mounted on the mower deck to help support and guide it along the ground. They prevent scalping and provide stability during operation.
  8. Deck Wash Port: Some mower decks feature a wash port for easy cleaning. It allows you to connect a garden hose to flush out grass clippings and debris from the underside of the deck.
  9. Discharge Chute: This is the opening on the mower deck where grass clippings are discharged during mowing. It may have a deflector or mulching attachment depending on the mower’s configuration.

John Deere 1025r Parts Catalog

The John Deere 1025R parts catalog can be found in several places:

  1. The John Deere website provides access to owner information, including parts diagrams and service manuals, for the 1025R.
  2. The AllTractorManuals.com website lists the parts catalog for the John Deere 1025R as one of the available manuals.
  3. The Weingartz website offers an illustrated diagram of the various components and parts for the 1025R compact utility tractor model.
  4. The JacksSmallEngines.com website also provides a parts lookup and exploded view for the John Deere 1025R.

John Deere 1025r Parts Manual

Main Sections

  1. ntroduction: This section provides an overview of the manual, including instructions on how to use it effectively, safety precautions, and general maintenance guidelines.
  2. Table of Contents: A detailed table of contents listing the sections and subsections covered in the manual, along with corresponding page numbers for easy reference.
  3. Illustrated Parts Breakdown: This section features detailed diagrams or illustrations of the tractor and its attachments, with each component labeled and numbered for identification.
  4. Part Number Index: A comprehensive list of part numbers referenced in the manual, organized alphabetically or numerically, allowing users to quickly locate specific parts.
  5. Part Descriptions: Detailed descriptions of each part, including its function, dimensions, material specifications, and any relevant notes or warnings.
  6. Assembly Instructions: Step-by-step instructions for assembling and installing various components, attachments, or accessories on the tractor, along with recommended tools and techniques.
  7. Maintenance Procedures: Guidelines and procedures for routine maintenance tasks, such as lubrication, fluid checks, filter replacements, and belt adjustments.
  8. Troubleshooting Guide: A troubleshooting section that helps users diagnose common problems or issues with the tractor and provides recommended solutions or repair procedures.
  9. Parts Ordering Information: Contact information for authorized John Deere dealers or distributors where users can order replacement parts or accessories mentioned in the manual.
  10. Appendices: Additional reference materials, such as wiring diagrams, technical specifications, conversion charts, or warranty information, may be included in the appendices.

John Deere 1025r 3 Point Hitch Parts

  1. 3-Point Hitch Arms: These are the main components of the 3-point hitch system. They extend from the rear of the tractor and provide attachment points for implements. The 3-point hitch arms are typically adjustable in terms of width and height to accommodate different implements.
  2. Top Link: The top link connects the 3-point hitch arms to the implement. It helps to control the implement’s angle and alignment during operation. The top link is adjustable in length to accommodate various implements and operating conditions.
  3. Stabilizers (Sway Bars): Stabilizers are used to prevent lateral movement of the 3-point hitch arms and provide additional stability when using heavy implements. They attach to the lower ends of the 3-point hitch arms and can be adjusted to provide the necessary tension.
  4. Lower Hitch Pins: These are the pins used to attach implements to the lower arms of the 3-point hitch. They secure the implement’s lower hitch points to the tractor’s hitch arms.
  5. Top Link Pin: The top link pin secures the top link to the implement and allows for adjustment of the top link length.
  6. Center Link Pin: In some configurations, there may be a center link connecting the tractor to the implement. The center link pin secures the center link to the implement.
  7. Draft Links: Draft links are adjustable links that connect the implement to the tractor’s hitch arms. They help control the depth and angle of the implement during operation.
  8. Lift Arms: These are the sections of the 3-point hitch arms that raise and lower the implements. They are typically controlled by the tractor’s hydraulic system.
  9. Hydraulic Cylinder: Some 3-point hitch systems may include a hydraulic cylinder for raising and lowering implements. This cylinder is controlled by the tractor’s hydraulic system and provides additional lifting power.

John Deere 1025r Parts List

  1. Engine Parts: Components related to the tractor’s engine, such as filters, belts, gaskets, seals, and engine block components.
  2. Transmission and Drivetrain Parts: Parts related to the tractor’s transmission, including gears, shafts, bearings, seals, clutches, and hydraulic components.
  3. Electrical Parts: Components related to the tractor’s electrical system, such as batteries, alternators, starters, wiring harnesses, switches, and lights.
  4. Hydraulic Parts: Parts associated with the tractor’s hydraulic system, including hoses, fittings, valves, cylinders, pumps, and hydraulic fluid reservoirs.
  5. Chassis and Frame Parts: Components related to the tractor’s chassis and frame, including panels, fenders, bumpers, roll bars, and mounting hardware.
  6. 3-Point Hitch Parts: Parts associated with the tractor’s 3-point hitch system, including arms, pins, stabilizers, draft links, top links, and lift components.
  7. Mower Deck Parts: Components related to the tractor’s mower deck, including blades, spindles, belts, pulleys, wheels, and discharge chute assemblies.
  8. Loader Parts: Parts associated with the tractor’s loader attachment, including buckets, cylinders, hydraulic hoses, mounting brackets, and joystick controls.
  9. Backhoe Parts (if equipped): Components related to the tractor’s backhoe attachment, including buckets, arms, hydraulic cylinders, stabilizers, and mounting hardware.
  10. Tire and Wheel Parts: Components related to the tractor’s tires and wheels, including tires, rims, wheel weights, tire chains, and valve stems.

John Deere 1025r Attachments

Common attachments include

  1. Front Loader: A front loader attachment allows the tractor to lift and move materials such as dirt, gravel, mulch, and pallets. It’s useful for loading, digging, grading, and carrying tasks.
  2. Backhoe: A backhoe attachment adds excavation capabilities to the tractor, allowing it to dig trenches, foundations, and utility lines. It’s ideal for landscaping, construction, and utility work.
  3. Mower Deck: A mower deck attachment enables the tractor to mow grass and maintain lawns, fields, and meadows. Mower decks come in various widths and styles to suit different applications.
  4. Box Blade: A box blade attachment is used for grading, leveling, and backfilling tasks. It’s equipped with adjustable scarifiers and a rear blade for cutting and shaping soil surfaces.
  5. Rotary Tiller: A rotary tiller attachment is designed for soil preparation and cultivation. It’s used for breaking up and tilling compacted soil, preparing seedbeds, and incorporating amendments.
  6. Snow Blower: A snow blower attachment allows the tractor to clear snow from driveways, sidewalks, and parking lots. It’s equipped with a rotating auger and impeller to discharge snow to the side.
  7. Front Blade: A front blade attachment is used for pushing and moving snow, dirt, and other materials. It’s adjustable for angling and leveling tasks and can be used for light grading and scraping.
  8. Post Hole Digger: A post hole digger attachment is used for drilling holes for fence posts, signposts, and other installations. It’s available in various sizes and configurations to accommodate different post diameters.
  9. Sprayer: A sprayer attachment enables the tractor to apply pesticides, herbicides, fertilizers, and other chemicals to crops, lawns, and gardens. It’s equipped with a tank, pump, and spraying mechanism.
  10. Pallet Forks: Pallet forks attachment allows the tractor to lift and carry palletized materials, such as bags, boxes, and building supplies. They’re commonly used for handling and transporting heavy loads.

John Deere 1025r Problems

Common problems include :

  1. Electrical Issues: Problems with the electrical system can include issues with starting, lighting, or other electrical components. Possible causes may include loose connections, faulty wiring, or a malfunctioning battery. Solutions may involve checking and tightening connections, inspecting wiring for damage, or replacing the battery if necessary.
  2. Hydraulic Leaks: Hydraulic leaks can occur in various parts of the tractor’s hydraulic system, such as hoses, fittings, or seals. Leaks may result from wear and tear, damage, or improper installation. Solutions may involve identifying and repairing the source of the leak, replacing damaged components, or tightening fittings.
  3. Overheating: Overheating can occur if the tractor’s cooling system is not functioning properly or if the engine is being operated under heavy loads for extended periods. Possible causes may include a low coolant level, a malfunctioning thermostat, a clogged radiator, or a faulty water pump. Solutions may involve checking and topping up coolant levels, inspecting and cleaning the radiator, or replacing faulty components.
  4. Transmission Issues: Transmission problems can manifest as difficulty shifting gears, loss of power, or unusual noises during operation. Possible causes may include low transmission fluid levels, worn-out clutch plates, or internal mechanical issues. Solutions may involve checking and topping up transmission fluid levels, inspecting and replacing worn-out components, or consulting a professional technician for diagnosis and repair.
  5. Steering Problems: Steering issues can include difficulty turning, uneven steering response, or excessive play in the steering wheel. Possible causes may include low hydraulic fluid levels, worn-out steering components, or improper alignment. Solutions may involve checking and topping up hydraulic fluid levels, inspecting and replacing worn-out parts, or adjusting the steering system for proper alignment.
  6. PTO (Power Take-Off) Problems: Issues with the tractor’s PTO system can result in difficulties engaging or disengaging attachments, loss of power, or unusual noises during operation. Possible causes may include damaged PTO shafts, worn-out clutch components, or electrical faults. Solutions may involve inspecting and replacing damaged parts, adjusting clutch settings, or troubleshooting electrical connections.
  7. Fuel System Issues: Problems with the fuel system can lead to issues such as engine stalling, rough idling, or loss of power. Possible causes may include contaminated fuel, clogged fuel filters, or malfunctioning fuel injectors. Solutions may involve draining and replacing contaminated fuel, replacing fuel filters, or cleaning and servicing fuel injectors.

John Deere 1025r Lift Capacity

  • The 1025R has a lift capacity of 525 kg (1,157 lbs) at the lift points.
  • However, the actual lift capacity can be higher than the rated specification. One source states the 1025R can lift over 955 lbs to a height of 59 inches.
  • In a real-world test, the 1025R was able to lift a load of over 1,026 lbs, though it could not lift that weight very high.
    4
  • The 1025R’s lift capacity can be further increased by using the optional mechanical self-leveling (MSL) loader, which can provide a 20-40% increase in lift capacity compared to non-self-leveling loaders.

So in summary, the John Deere 1025R has a rated lift capacity of 1,157 lbs, but can often lift significantly more weight, especially when equipped with the MSL loader option.

John Deere 1025r Accessories

Popular accessories include

  1. Canopy: A canopy attachment provides shade and protection from the sun and light rain while operating the tractor. It helps keep the operator comfortable during long hours of use in hot weather.
  2. Seat Covers: Seat covers can help protect the tractor’s seats from wear and tear, dirt, and UV damage. They come in various materials and designs to suit different preferences.
  3. Toolbox: A toolbox attachment mounts to the tractor’s frame and provides convenient storage for tools, equipment, and accessories needed for maintenance and repair tasks.
  4. Fender Guards: Fender guards help protect the tractor’s fenders from scratches, dents, and other damage caused by debris, branches, or impacts during operation.
  5. Headlights and Work Lights: Additional headlights or work lights can be installed to improve visibility and safety when operating the tractor in low-light conditions or at night.
  6. LED Light Kits: LED light kits offer brighter, more energy-efficient lighting compared to standard halogen bulbs. They can be installed to enhance visibility and illuminate the work area around the tractor.
  7. Weight Brackets and Suitcase Weights: Weight brackets allow for the attachment of suitcase weights to the tractor’s front or rear, providing added stability and traction when using heavy implements or working on uneven terrain.
  8. Front Bumper: A front bumper attachment adds protection to the tractor’s front end and grille from impacts with obstacles, debris, or other hazards.
  9. Brush Guards: Brush guards help protect the tractor’s headlights and grille from damage caused by branches, brush, and other vegetation when operating in dense or wooded areas.
  10. Receiver Hitch: A receiver hitch attachment allows for the towing of trailers, carts, and other equipment with a standard hitch receiver. It adds versatility to the tractor for hauling tasks.
  11. Ballast Box: A ballast box attachment adds weight to the tractor’s rear for improved stability and traction when using heavy rear-mounted implements or operating on slopes.
  12. Wheel Spacers: Wheel spacers can be installed to adjust the tractor’s wheel stance for added stability, clearance, or to accommodate wider tires.

John Deere 1025r Backhoe

The John Deere 1025R can be equipped with the 260B backhoe attachment, which provides the following specifications:

  • Digging depth of 6 ft, 2 in (1.9 m)
  • SAE dipperstick digging force of 1,187 lb (538 kg)
  • SAE bucket digging force of 2,036 lb (924 kg)
  • Swing arc of 150 degrees
  • Boom lift capacity of 285 lb (129 kg)
  • Transport height of 6 ft, 6 in (1.7 m)
  • Stabilizer spread width of 4 ft, 10 in (1.5 m) up and 6 ft, 2 in (1.9 m) down

The 260B backhoe is designed specifically for the 1025R tractor and provides “best-in-class features priced competitively” compared to other backhoes in its class. It features an easy-access step, upgraded hydraulic valve for smooth operation, and optional field-install thumb.2

John Deere 1025r Weight

The weight of the John Deere 1025R compact utility tractor is as follows:

  • The shipping weight of the 1025R tractor itself is 1,444 lbs (654 kg).
  • When equipped with a 120R non-self-leveling (NSL) loader, the total weight is around 2,300 lbs (1,043 kg).
  • With a 120R mechanical self-leveling (MSL) loader, the total weight is approximately 2,800 lbs (1,270 kg).
  • Adding a 260B backhoe attachment can increase the total weight to around 2,800 lbs (1,270 kg) or more.

So in summary, the base weight of the John Deere 1025R tractor is 1,444 lbs, but the total weight can range from 2,300 lbs up to 2,800 lbs or more depending on the loader and other attachments added.

John Deere 1025r Weight with Loader

The weight of the John Deere 1025R compact utility tractor with a loader attachment can vary depending on the specific loader model:

  • The 120R non-self-leveling (NSL) loader weighs 517 lbs (235 kg) for the 1025R model.
  • The 120R mechanical self-leveling (MSL) loader weighs 680 lbs (309 kg) for the 1025R.
  • In a real-world test, a 1025R equipped with the 120R MSL loader had a total weight of 2,800 lbs (1,270 kg).
  • If the 1025R tractor itself weighs around 1,800 lbs (816 kg), and the 260B backhoe attachment weighs an additional 1,000 lbs (454 kg).

So in summary, the total weight of a John Deere 1025R compact utility tractor with a loader attachment can range from around 2,300 lbs (1,043 kg) with a non-self-leveling loader, up to 2,800 lbs (1,270 kg) or more with a self-leveling loader installed.

The exact weight will depend on the specific loader model and any other attachments or accessories added.

John Deere 1025r Oil filter

The John Deere 1025R uses the M806418 oil filter. This is a genuine John Deere oil filter that is specifically designed for the Yanmar 1.3L 3-cylinder diesel engine used in the 1025R compact utility tractor.

Replace the M806418 oil filter every 200 hours of operation, and annually if less than 200 hours of operation.

John Deere 1023e v 1025r

Comparison of the John Deere 1023E and 1025R:

  1. Engine Power:
    • The John Deere 1023E is equipped with a 22.9 horsepower diesel engine.
    • The John Deere 1025R features a slightly more powerful 24 horsepower diesel engine.
  2. Size and Weight:
    • Both tractors have similar dimensions, but the 1025R may be slightly larger and heavier due to its larger engine and additional features.
  3. Transmission:
    • Both models come with a hydrostatic transmission, offering smooth and easy operation with infinite speeds within each range.
  4. Loader and Backhoe Compatibility:
    • The 1025R typically offers more loader and backhoe options compared to the 1023E, allowing for greater versatility and attachment compatibility.
  5. 3-Point Hitch and Hydraulic Capacity:
    • While both tractors feature a Category 1 3-point hitch, the 1025R may have slightly higher hydraulic capacity, allowing it to handle heavier implements and attachments more effectively.
  6. Price:
    • Generally, the John Deere 1023E tends to be more affordable than the 1025R, making it a popular choice for budget-conscious buyers.
  7. Comfort and Convenience Features:
    • The 1025R may offer more comfort and convenience features as standard or optional equipment, such as a more comfortable seat, tilt steering wheel, and more ergonomic controls.
  8. Intended Use:
    • Both tractors are suitable for a variety of tasks, including landscaping, property maintenance, light construction, and agricultural work. However, the 1025R may be better suited for slightly larger properties or heavier-duty tasks due to its higher horsepower and additional features.

John Deere 2025r v 1025r

Comparison of the John Deere 2025R and 1025R:

  1. Engine Power:
    • The John Deere 2025R is equipped with a more powerful 24.2 horsepower diesel engine.
    • The John Deere 1025R features a slightly less powerful 23.9 horsepower diesel engine.
  2. Size and Weight:
    • The 2025R is generally larger and heavier than the 1025R, allowing for increased stability and lifting capacity.
    • The larger size of the 2025R may also make it better suited for larger properties and heavier-duty tasks.
  3. Transmission:
    • Both models come with a hydrostatic transmission, offering smooth and easy operation with infinite speeds within each range.
  4. Loader and Backhoe Compatibility:
    • The 2025R typically offers more loader and backhoe options compared to the 1025R, providing greater versatility and attachment compatibility.
  5. 3-Point Hitch and Hydraulic Capacity:
    • While both tractors feature a Category 1 3-point hitch, the 2025R may have a higher hydraulic capacity, allowing it to handle heavier implements and attachments more effectively.
  6. Comfort and Convenience Features:
    • The 2025R may offer more comfort and convenience features as standard or optional equipment, such as a more comfortable seat, tilt steering wheel, and more ergonomic controls.
  7. Intended Use:
    • Both tractors are suitable for a variety of tasks, including landscaping, property maintenance, light construction, and agricultural work.
    • The 2025R may be better suited for larger properties, heavier-duty tasks, and more frequent or intensive use due to its higher horsepower and larger size.
  8. Price:
    • Generally, the John Deere 2025R tends to be more expensive than the 1025R, reflecting its higher horsepower and additional features.

John Deere 1025r TLB

The term “TLB” stands for “Tractor Loader Backhoe.” In the context of the John Deere 1025R TLB, it refers to a specific configuration of the John Deere 1025R compact utility tractor that includes a loader and a backhoe attachment.

The John Deere 1025R TLB is a versatile machine that combines the capabilities of a compact tractor with those of a loader and a backhoe. It’s commonly used for a variety of tasks, including digging, trenching, material handling, landscaping, and property maintenance.

Here’s what each component of the John Deere 1025R TLB entails:

  1. Tractor (1025R): The tractor itself is a compact utility tractor with a diesel engine, hydrostatic transmission, and four-wheel drive. It provides the power and mobility needed to operate the loader and backhoe attachments.
  2. Loader Attachment: The loader attachment consists of a front-mounted bucket and hydraulic arms that allow the operator to lift, lower, and tilt the bucket for loading, hauling, and material handling tasks. It’s commonly used for tasks such as moving dirt, gravel, mulch, and other materials.
  3. Backhoe Attachment: The backhoe attachment is mounted on the rear of the tractor and consists of a digging arm, bucket, and hydraulic controls. It allows the operator to dig trenches, excavate holes, and perform other earthmoving tasks. The backhoe attachment adds versatility to the tractor, allowing it to tackle a wide range of projects.

The John Deere 1025R TLB configuration offers increased productivity and efficiency compared to using separate machines for loading, hauling, and digging tasks.

It’s popular among homeowners, landscapers, contractors, and small-scale farmers who need a compact and versatile machine for various projects.

John Deere 1025r Loader Lift Capacity

The John Deere 1025R loader lift capacity is:

  • The rated lift capacity of the 1025R with the 120R loader is 836 lbs (380 kg).
  • However, real-world testing has shown the 1025R can actually lift over 1,040 lbs (472 kg) with the 120R loader, which is about 20% more than the rated capacity.
  • The 120R mechanical self-leveling (MSL) loader option can provide a 20-40% increase in lift capacity compared to the non-self-leveling version
  • With the MSL loader, the 1025R’s lift capacity is rated at 680 lbs (309 kg)

So in summary, while the 1025R has a rated lift capacity of 836 lbs, real-world testing has shown it can actually lift over 1,000 lbs, and the optional MSL loader can further increase the lift capacity by 20-40%. The tractor appears to be underrated for its actual lifting capabilities.

John Deere 1025r Length with Loader

The John Deere 1025R compact utility tractor has the following length dimensions when equipped with a loader:

  • With the 120R loader attached, the total length of the 1025R is 177 inches (449 cm).
  • This length measurement is specifically for the 1025R with the loader-backhoe configuration, which extends the overall length of the tractor.

The base length of the 1025R tractor alone is:

  • 87.6 inches (222 cm) in length.

So in summary, the John Deere 1025R has a base length of 87.6 inches, but when equipped with a loader attachment like the 120R, the total length increases to 177 inches. The loader significantly adds to the overall length of the 1025R compact utility tractor.

John Deere 1025r Dimensions

The key dimensions of the John Deere 1025R compact utility tractor are:
  • Length:
    • 87.6 inches (222 cm) without a loader
    • 102.6 inches (260 cm) with a hitch
    • 177 inches (449 cm) with a loader-backhoe configuration
  • Width:
    • 47.2 inches (119 cm) with R3 tires
  • Height:
    • 41.5 inches (105 cm) at the hood
    • 86.2 inches (218 cm) with the ROPS up
  • Wheelbase: 57.1 inches (145 cm)
  • Front axle clearance: 7.7 inches (19 cm)
  • Front tread: 32.2 inches (81 cm)

John Deere 1025r Pallet Forks

The best option for pallet forks on the John Deere 1025R compact utility tractor appears to be the lightweight pallet forks from HLA:

  • These HLA lightweight pallet forks weigh only 190 lbs with 36-inch tines, which is significantly less than standard pallet forks that can weigh 300-360 lbs.
  • The lighter weight of these forks allows them to better match the lift capacity of the 1025R’s loader, which is rated at 836 lbs.
  • Real-world testing has shown the 1025R can actually lift over 1,040 lbs with the HLA lightweight pallet forks.
  • The HLA forks come in John Deere green and can be equipped with either the John Deere quick attach or skid steer quick attach bracket.
  • Users on forums have also recommended the Titan Attachments pallet fork frame as a good option for the 1025R.

In summary, the best pallet forks for the John Deere 1025R appear to be the lightweight 190 lb HLA forks, which maximize the tractor’s lift capacity compared to heavier standard pallet forks. The Titan Attachments pallet fork frame is another well-reviewed option.

Key Features

The key features of the John Deere 1025R pallet forks are:

  1. Lightweight design – The HLA lightweight pallet forks weigh only 190 lbs with 36-inch tines, significantly less than standard pallet forks that can weigh 300-360 lbs.
  2. Matched to 1025R lift capacity – The lighter weight of the HLA forks allows them to better match the 836 lb lift capacity of the 1025R’s loader.
  3. Available in different lengths – Pallet fork lengths of 36 inches, 42 inches, and 48 inches are available to suit different needs.
  4. Adjustable fork width – The pallet fork tines are adjustable in width along the carriage rail
  5. Integrated tie-off point – The pallet fork carriage has an integrated tie-off point to help secure loads
  6. Compatible with quick attach – The pallet forks can be equipped with either the John Deere quick attach or skid steer quick attach bracket
  7. Durable construction – The pallet fork carriage and tines are made from heavy-duty 1/4″ steel plate for strength and durability
  8. Powder coated in John Deere green – The pallet forks are available in a John Deere green finish.

John Deere 1025r Battery

The John Deere 1025R uses a standard automotive-style battery. Specifically:

  • The recommended battery for the 1025R is a Group U1R battery
  • This is a 12V, 500 CCA (cold cranking amps) battery that is commonly used in many John Deere compact utility tractors.
  • The battery is located under the hood of the 1025R and can be easily accessed for replacement or maintenance.
  • When changing the battery, it’s important to follow the proper steps to disconnect the old battery and connect the new one correctly.
  • Accessories like an engine block heater adapter and coolant heater kit are also available for the 1025R to assist with cold weather starting

So in summary, the John Deere 1025R uses a standard Group U1R 12V, 500 CCA automotive-style battery that can be readily replaced when needed. Proper battery maintenance and accessories are recommended for optimal performance.

John Deere 1025r Warranty

The John Deere 1025R is covered by the following warranty terms:

  • The 1025R has a limited warranty provided by John Deere to the original purchaser.
  • Under this warranty, John Deere will repair or replace, at its option, any covered part that is found to be defective in material or workmanship during the applicable warranty term.
  • The warranty term for the 1025R’s powertrain (engine, transmission, differential, etc.) is 24 months or 1,000 hours, whichever comes first.
  • The warranty does not cover normal maintenance parts and service, or any equipment that has been altered or modified without John Deere’s approval.
  • To secure warranty service, the owner must report the defect to an authorized dealer and make the equipment available within the warranty period.
  • The warranty is transferable to a new owner, provided an authorized John Deere dealer is notified of the ownership change.

So in summary, the John Deere 1025R is covered by a 24-month/1,000-hour limited warranty on the powertrain, with specific terms and conditions that must be met to receive warranty service.

John Deere 1025r Tiller

The 1025R is compatible with a variety of tiller attachments, including:

  • The Ideal 48″ rotary tiller, which is designed for subcompact tractors between 15-35 HP like the 1025R. It features 6 rotors with 4 flanges each, adjustable depth, and a slip clutch.
  • A King Kutter XB tiller.

The 1025R is compatible with a variety of tiller attachments in the 48-inch size range, allowing it to tackle tilling tasks for landscaping, gardening, and nursery applications. The tractor’s 25 HP engine and 4WD provide the power and traction needed to use these tiller implements effectively.

John Deere 1025r Fuel Capacity

The fuel tank capacity of the John Deere 1025R compact utility tractor is 5.7 gallons (21.2 liters).

Specifically, the key details are:

  • The 1025R has a fuel tank capacity of 5.7 gallons (21.2 liters).
  • The fuel system on the 1025R uses an indirect injection type.
  • The tractor has a 40 amp alternator and a 500 CCA battery

So in summary, the John Deere 1025R compact utility tractor has a fuel tank capacity of 5.7 gallons or 21.2 liters, which powers its Yanmar 3-cylinder diesel engine with an indirect fuel injection system.

John Deere 1025r Horsepower

The John Deere 1025R compact utility tractor has the following horsepower specifications:

  • Gross Power: 23.9 hp (17 kW)
  • PTO Power: 18 hp (13.4 kW)

 The 1025R has a gross engine power of 23.9 hp (17 kW). Additionally, the tractor is rated to provide 18 hp (13.4 kW) of power at the PTO (power take-off).

So in summary, the key horsepower ratings for the John Deere 1025R compact utility tractor are:

  • Gross Engine Power: 23.9 hp (17 kW)
  • PTO Power: 18 hp (13.4 kW)

This engine power provides the 1025R with the capability to handle a variety of implements and attachments for landscaping, farming, and other applications.

John Deere Parts

John Deere Parts

John Deere offers a comprehensive range of high-quality genuine parts for their agricultural equipment, including tractors, combines, sprayers, and balers. These parts are designed and manufactured to the same standards as the original equipment, ensuring a perfect fit and optimal performance.

John Deere has been remanufacturing parts and components for over 20 years. The remanufacturing process involves replacing failed and worn parts with original parts, and then inspecting and testing the components to original performance specifications. This provides an environmentally-friendly and cost-effective repair alternative.

John Deere Aftermarket Parts

In addition to genuine John Deere parts, the company also offers alternative aftermarket parts that are redesigned to fit older John Deere machines. These alternative parts are authorized to fit John Deere equipment, but may not meet the same strict quality and specification standards as the genuine parts.

John Deere Parts Catalog

John Deere’s online parts catalog, JDParts, allows customers to search for and purchase parts 24/7. The catalog provides instant pricing and availability information, making it easy to find and order the right parts.

John Deere Parts – Ordering Online

Visit the John Deere online parts catalog at shop.deere.com or the John Deere UK & IE website. You can search for parts by entering your machine’s model, name, or serial number. This will allow you to find the specific parts you need for your John Deere equipment. Once you’ve found the parts you need, you can select and reserve them with just one click.

You have the option to either pick up the parts at your local John Deere dealer through the “Click & Collect” service, or have them delivered directly to your door. The online platform provides a user-friendly experience, with clearly laid out tables showing product images, part numbers, and pricing information. This makes it easy to browse and order the right John Deere parts.

John Deere Mower Parts

The most commonly replaced parts on John Deere mowers tend to be: Mower Blades, Mower Belts, Mulching Kits, Batteries, Scraper Parts, Drive Shaft Keys, Wash Ports.

Mower Blades: These are subjected to wear and tear over time from hitting objects or mowing through abrasive materials like sand. Dull blades can tear grass instead of cutting it cleanly, leading to an uneven lawn and increased fuel consumption. Replacing mower blades is a relatively simple task that can be done at home.

Air Filters: A clogged air filter can restrict airflow to the engine, reducing power and performance. It can also allow dirt and debris into the engine, which can cause wear and tear. Air filters should be replaced regularly according to the manufacturer’s recommendations.

Spark Plugs: Spark plugs ignite the air-fuel mixture in the engine. Worn-out spark plugs can cause difficulty starting, rough idling, and decreased power. Spark plugs should be replaced at regular intervals as part of routine maintenance.

Drive Belts: The drive belts transfer power from the engine to the mower deck and other attachments. Worn-out belts can slip or break, which can prevent the mower from functioning properly. Drive belts should be inspected regularly for signs of wear and tear and replaced when necessary.

Tires: Just like car tires, John Deere mower tires can wear out over time and need to be replaced. Uneven wear or damage from punctures can also necessitate replacing a tire.

John Deere x350 Parts

John Deere Tractor Parts

Some of the main John Deere tractor parts that are commonly replaced:

Engine Parts: These include engine filters, air filters, oil filters, spark plugs, and belts. Regular replacement of these parts is essential for maintaining engine performance and longevity.

Tires: Tractor tires are designed to withstand tough conditions, but they eventually wear out and need to be replaced. The type of tire you need will depend on the size and application of your tractor.

Hydraulic System Components: The hydraulic system is responsible for powering many of the tractor’s functions, such as lifting and lowering attachments. Common hydraulic system components that need to be replaced include hoses, filters, and pumps.

Drive Train Components: The drive train transfers power from the engine to the wheels. Common drive train components that need to be replaced include clutches, transmissions, and differentials.

Electrical System Components: The electrical system provides power for the tractor’s lights, starter, and other electrical components. Common electrical system components that need to be replaced include batteries, alternators, and starters.

Body Parts: Body parts such as fenders, hoods, and grilles can be damaged by wear and tear or accidents. These parts can be replaced to keep your tractor looking its best.

Attachments: John Deere tractors can be used with a variety of attachments, such as mowers, loaders, and backhoes. These attachments can wear out over time and need to be replaced.

John Deere 1025r Parts

John Deere Gator Parts

Some of the main John Deere Gator parts include:

Engine: The engine is the heart of the Gator and provides power to the wheels. John Deere Gators typically use gasoline or diesel engines.

Drivetrain: The drivetrain transfers power from the engine to the wheels. It includes components like the transmission, axles, and driveshafts.

Suspension: The suspension system helps to absorb bumps and vibrations from the ground, providing a smoother ride.

Brakes: The brakes are used to slow down and stop the Gator. John Deere Gators typically use hydraulic disc brakes.

Steering: The steering system allows you to control the direction of the Gator. John Deere Gators typically use rack and pinion steering.

Body: The body of the Gator is the frame that supports all of the other components. It is typically made of steel or plastic.

Wheels and tires: The wheels and tires are what make contact with the ground and allow the Gator to move. The size and type of wheels and tires will vary depending on the model of Gator and its intended use.

Electrical system: The electrical system provides power to the lights, starter, and other electrical components.

John Deere Construction Parts

Here’s a breakdown of the main parts categories across these machines:

Engine: The engine provides power to the entire machine. John Deere construction equipment utilizes diesel engines known for their durability and power.

Drivetrain: Transfers power from the engine to the wheels or tracks. This system consists of the transmission, axles, and driveshafts.

Hydraulics: The hydraulic system powers functions like attachment actuation, bucket movement, and machine movement (on some models). It consists of pumps, valves, cylinders, and hydraulic fluid.

Electrical System: Provides power to the lights, starter, instruments, and other electrical components.

Frame: The frame is the backbone of the machine, supporting all other components and bearings the brunt of the machine’s weight and stress.

Undercarriage (for tracked machines): The undercarriage consists of the tracks, track rollers, idlers, and sprockets. It provides stability and distributes the machine’s weight over a larger area.

Attachments: Depending on the machine’s function, various attachments can be used. Common attachments include buckets, grapples, hammers, blades, plows, and snowblowers.

John Deere Engine Parts

Common Parts Include :

Block: The engine block is the core of the engine, housing the cylinders, pistons, crankshaft, and other essential components. It’s made of durable cast iron to withstand the high temperatures and pressures generated during combustion.

Cylinder head: The cylinder head sits on top of the engine block and seals the combustion chambers. It contains valves that control the intake and exhaust of air and fuel.

Pistons: Pistons move up and down within the cylinders, compressing the air-fuel mixture and transmitting the force of combustion to the crankshaft.

Crankshaft: The crankshaft is a rotating shaft that converts the reciprocating motion of the pistons into rotational motion. It transmits this power to other engine components like the flywheel and driveshaft.

Connecting rods: Connecting rods connect the pistons to the crankshaft, allowing the pistons’ up-and-down motion to be translated into the crankshaft’s rotation.

Valvetrain: The valvetrain consists of the camshaft, valves, springs, and pushrods. It controls the opening and closing of the intake and exhaust valves at precise moments during the engine cycle.

Intake system: The intake system delivers air to the engine. It typically includes an air filter, intake manifold, and throttle body.

Fuel system: The fuel system delivers fuel to the engine. It includes components like the fuel pump, fuel injectors, and fuel filter.

Cooling system: The cooling system regulates engine temperature. It consists of a radiator, water pump, thermostat, and coolant.

Lubrication system: The lubrication system circulates oil throughout the engine to reduce friction and wear on moving parts. It includes an oil pump, oil filter, and various passages within the engine block and head.

Exhaust system: The exhaust system removes exhaust gases from the engine. It includes the exhaust manifold, catalytic converter (if equipped), muffler, and tailpipe.
